Asetek is a Danish manufacturer of computer components that has recently started offering products for sim racing. Asetek Invicta Direct Drive Wheelbase is their first Direct Drive base based on Simucube technology.
When we set out to develop our range of direct drive wheelbases, we wanted to develop the best sim racing wheelbases on the market as measured on all parameters but without breaking the bank. We had greater aspirations than just reselling a standard industrial servo motor and then trying to adapt everything else around it. It was a tough task but as we did with our award-winning pedals and steering wheels, we started from a clean sheet.
We bought and implemented IP from market-leading vendors, teamed up with Mige, a well-known motor supplier to sim racing, and after thousands of man-hours of developing from the ground up the electronics, software, firmware, mechanics, cooperation, design, test, and validation, we are now ready! Please meet the Invicta™ 27Nm Direct Drive Wheelbase!
True to the spirit of our other products, with Asetek SimSports® you will get the same quality, durability, engineering excellence – and most importantly – the same user experience, independent of whether you buy our entry-level La Prima™ series or our top-tier Invicta™ products. Each wheelbase from 12-27Nm features a high-end 22-bit encoder, slipring, and electronics, providing an unrivaled driving experience, leaving cogging and lagging in ancient history. All vital parts are of course made of aluminum and steel.
All Asetek SimSports® wheelbases provide smooth, super responsive, and precise feedback to the driver, where you will feel even the smallest bumps and curbs on the road. As an example – each of our wheelbases has a resolution of 0,000085 degrees or roughly 4.000.000 steps in just one revolution of the wheel! In other words, with an Asetek SimSports® wheelbase, you do not have to choose between a true high-fidelity driver experience and a low price. You get it all!
Images
Videos
Features
Tech specs
- Exquisite, radical, and minimalistic Danish industrial design
- Made in Denmark
- Anodized extruded aluminum housing
- Direct Drive Force Feedback
- Peak Torque of 27Nm (Max 40 seconds continuosly)
- Peak Slew rate: 9.4 Nm/ms
- Encoder resolution: 22bit / 0,000085 degrees / 4.000.000 steps
- 6×25 Programmable RGB LEDs that can be adjusted, dimmed or completely turned off in Asetek SimSports® RaceHub™
- Asetek SimSports® Quick Release
- 400w power supply
- Slipring designed and tested to +200.000.000 rotations
Software Features
- Setup and save profile presets – Customize your settings to fit your car, track, and conditions
- Adjust steering range, bumpstop hardness, and bumpstop range
- Adjust Overall Force, Basic Damping, and Basic Smoothing
Dimensions
- Height: 133mm
- Width: 132mm
- Length (Incl. Quick Release): 327mm
- Weight: 11,3kg
Compatibility
- PC: YES
- PS4: NO
- PS3: NO
- XBox One: NO
Buy It!
Asetek Invicta Direct Drive WheelbaseYou can buy it on Asetek official website (5% OFF using this coupon: SIMRACER.ES)
